UNC (Unified National Coarse) threads are part of the Unified Thread Standard (UTS), primarily used in inch-based fastening systems. These threads have a coarse pitch, making them stronger, more durable, and resistant to wear compared to fine threads.
UNC threads are commonly used in:
- General-purpose fasteners (bolts, screws, nuts)
- Structural applications (construction, automotive, and heavy machinery)
- Soft material fastening (aluminum, plastics, and wood applications)
This standard is closely related to:
- UNF (Unified National Fine) (For applications needing better grip and higher thread engagement.)
- UNEF (Unified National Extra Fine) (For high-precision applications.)
Technical Details
UNC threads are characterized by:
✅ A 60° thread angle (standardized for strength and compatibility)
✅ Greater thread depth (stronger engagement in soft materials)
✅ Better resistance to stripping and loosening
✅ Faster assembly due to coarser pitch spacing
UNC Thread Profile Parameters
- Thread Angle: 60°
- Crest Rounding: Defined for smooth engagement
- Tolerances: Defined in ANSI B1.1 for external and internal threads
UNC Standard Thread Sizes & Dimensions
Below is an extended table covering a wider range of standard UNC thread sizes.
Standard UNC Threads – Major, Minor, and Pitch Diameters
| Nominal Size (inches) | Threads Per Inch (TPI) | Major Diameter (in) | Pitch Diameter (in) | Minor Diameter (in) | Tap Drill Size (in) |
|---|---|---|---|---|---|
| #0 | 80 | 0.0600 | 0.0513 | 0.0457 | 0.0465 |
| #1 | 64 | 0.0730 | 0.0629 | 0.0561 | 0.0570 |
| #2 | 56 | 0.0860 | 0.0749 | 0.0678 | 0.0730 |
| #3 | 48 | 0.0990 | 0.0864 | 0.0786 | 0.0890 |
| #4 | 40 | 0.1120 | 0.0977 | 0.0896 | 0.0930 |
| #5 | 40 | 0.1250 | 0.1107 | 0.1014 | 0.1060 |
| #6 | 32 | 0.1380 | 0.1205 | 0.1113 | 0.1200 |
| #8 | 32 | 0.1640 | 0.1465 | 0.1375 | 0.1360 |
| #10 | 24 | 0.1900 | 0.1609 | 0.1511 | 0.1590 |
| 1/4″ | 20 | 0.2500 | 0.2175 | 0.2071 | 0.2010 |
| 5/16″ | 18 | 0.3125 | 0.2733 | 0.2622 | 0.2570 |
| 3/8″ | 16 | 0.3750 | 0.3277 | 0.3159 | 0.3120 |
| 7/16″ | 14 | 0.4375 | 0.3822 | 0.3697 | 0.3680 |
| 1/2″ | 13 | 0.5000 | 0.4339 | 0.4203 | 0.4210 |
| 9/16″ | 12 | 0.5625 | 0.4882 | 0.4739 | 0.4840 |
| 5/8″ | 11 | 0.6250 | 0.5421 | 0.5269 | 0.5310 |
| 3/4″ | 10 | 0.7500 | 0.6495 | 0.6335 | 0.6560 |
| 7/8″ | 9 | 0.8750 | 0.7565 | 0.7395 | 0.7660 |
| 1″ | 8 | 1.0000 | 0.8636 | 0.8466 | 0.9060 |
🔹 Note: The tap drill size is recommended for internal thread cutting.
UNC Standard Thread Dimensions in Metric (mm)
| Nominal Size | Major Diameter (mm) | Pitch Diameter (mm) | Minor Diameter (mm) | Tap Drill Size (mm) |
|---|---|---|---|---|
| #0 | 1.52 | 1.30 | 1.16 | 1.18 |
| #1 | 1.85 | 1.60 | 1.42 | 1.45 |
| #2 | 2.18 | 1.90 | 1.72 | 1.85 |
| #3 | 2.51 | 2.19 | 2.00 | 2.26 |
| #4 | 2.84 | 2.48 | 2.28 | 2.36 |
| #5 | 3.18 | 2.81 | 2.58 | 2.69 |
| #6 | 3.51 | 3.06 | 2.83 | 3.05 |
| #8 | 4.17 | 3.72 | 3.49 | 3.45 |
| #10 | 4.83 | 4.09 | 3.84 | 4.04 |
| 1/4″ | 6.35 | 5.52 | 5.26 | 5.11 |
| 5/16″ | 7.94 | 6.95 | 6.66 | 6.53 |
| 3/8″ | 9.53 | 8.32 | 8.02 | 7.92 |
| 7/16″ | 11.11 | 9.71 | 9.39 | 9.35 |
| 1/2″ | 12.70 | 11.02 | 10.67 | 10.69 |
| 9/16″ | 14.29 | 12.40 | 12.04 | 12.29 |
| 5/8″ | 15.88 | 13.77 | 13.39 | 13.49 |
| 3/4″ | 19.05 | 16.50 | 16.09 | 16.66 |
| 7/8″ | 22.23 | 19.22 | 18.79 | 19.46 |
| 1″ | 25.40 | 21.94 | 21.50 | 23.01 |
🔹 Note: The tap drill size is recommended for internal thread cutting.
Applications of UNC Threads
UNC threads are ideal for:
- Structural Fasteners (Bridges, buildings, and heavy-duty joints)
- Automotive Components (Chassis fasteners, engine mounts, suspension parts)
- Aerospace Applications (Where coarse threads are required in softer materials like aluminum.)
- General Manufacturing (Machinery, tools, industrial equipment.)
UNC threads are preferred over UNF (fine-pitch) threads in applications where:
✅ Quick assembly and disassembly are required
✅ Greater resistance to stripping is needed
✅ Threads will be exposed to vibration or high loads
Related Inch-Based Thread Standards
After reviewing UNC, you may also find the following standards useful:
- UNF – Unified National Fine (Higher strength in thinner materials.)
- UNEF – Unified National Extra Fine (Precision threads for specialized applications.)
- UNS – Unified National Special (Custom pitch threads for non-standard applications.)
- UNJ – Unified J-Form Threads (Modified UN threads with increased root radius for aerospace applications.)
- BSW – British Standard Whitworth (Traditional UK coarse threads.)
These links allow users to navigate easily between related standards.
